Description
Input Voltage:
36~72Vdc
Output Voltage #1:
5Vdc
Output #1 Max Current:
20 Amps
Output Voltage #2:
24Vdc
Output #2 Max Current:
3 Amps
Output Voltage #3:
12Vdc
Output #3 Max Current:
2 Amps
Output Voltage #4:
-12Vdc
Output #4 Max Current:
2 Amps
Max Power:
185 Watts
Known Country of Origin:
USA
Features
IPD DC4-185-4006-CH DC/DC Converter with medical approvals
DC input range: 36~72Vdc (48Vdc)
Operating temperature: 0~+70°C
EN 60950-1 ITE certification and EN 60601-1 medical certification
Small compact size, open frame dimensions: 4.36×7.23×1.74
Available in open frame or optional cover
Protections: over voltage / over power
Integrated Power Designs 2 year warranty
